MC Multigigabit
Part Number: 1415/1416
Order now

The MC MultiGigabit from Technica Engineering establishes a direct point-to-point conversion between Automotive ECUs using any of 2.5/5/10GBASE-T1 multigigabit standards and a SFP+ module compatible with any multigigabit ethernet interface. In the conversion, no packets are stored or modified, the conversion takes place on the physical layer with the highest proven reliability.

This device uses the 88Q4364 2.5G/5G/10GBASE-T1 IEEE 802.3ch compliant Automotive Ethernet PHY, is one of the first implementations of a Multi-Gigabit Automotive Ethernet physical layer media converter. We ensure a trustworthy and effective tool to our customers that are looking for a cost-efficient, quick, and manageable solution for their testing requirements, with no latency and no packet loss.


The MC Multigigabit features bi-directional conversion between automotive multigigabit Ethernet standards (2.5/5/10GBASE-T1) to any other ethernet standard through the SFP+ module and the rate matching feature enables possibility to interface between different line speeds. No customized driver is needed to interact with this MediaConverter.

A convenient housing made of galvanized sheet steel, coupled with DIP switches for ease of configuration, enables the user to interact with the converter effortlessly. Its design makes it portable and easy to install in test racks. The metal housing makes it robust with IP20 protection. The devices can also be accessed using the USB connector to read PHY register values as well as information regarding link quality and SQI. With the in-built status LEDs, the operation of the device is transparent and aids the tester to detect link-up and data transmission visually.

Thus, the MC Multigigabit is the ideal solution for working quickly and efficiently with the new 2.5/5/10GBASE-T1 technology without the burden of extra-wiring, customized connectors, and vendor-specific tools.

  • Converts between 10GBASE-T1 Automotive Gigabit Ethernet and 10GBASE-T Standard Gigabit Ethernet or optical Ethernet
  • 1 × H-MTD port for 10GBASE-T1 Automotive Ethernet
  • 1 × Standard SFP+ port
  • 4 × Status LEDs
  • Included in scope of delivery: Tyco MQS socket, 1 × Automotive H-MTD connector, Cableset (Power, 10GBASE-T1), Additional optical components
  • 1 × MQS connector
  • Voltage requirement: 12-24 volt DC
  • Stainless steel housing
  • Size: 95 × 95 × 32mm


If you have any question or you are wishing to receive the User Manual or more information on MC MultiGigabit, feel free to contact us at
